C236 WSI Server/Workstation Help...No Video |
Post Reply
|
| Author | |
wardog
Moderator Group
Joined: 15 Jul 2015 Status: Offline Points: 6447 |
 Post Options
 Thanks(0)
 Quote Reply
 Topic: C236 WSI Server/Workstation Help...No VideoPosted: 22 Feb 2017 at 7:33pm |
Rather expensive oops.  That sux big time.This happens here a lot too. |
|
 |
|
|
ARAMP1
Newbie
Joined: 22 Feb 2017 Location: Memphis, TN Status: Offline Points: 59 |
Post Options
Thanks(0)
Quote Reply
Posted: 22 Feb 2017 at 3:20pm |
|
Just figured out the E3-1240 doesn't have on board video. It's disabled on that chip. I need a E3-1245 (model that ends in 5) or a video card.
 |
|
|
|
|
ARAMP1
Newbie
Joined: 22 Feb 2017 Location: Memphis, TN Status: Offline Points: 59 |
Post Options
Thanks(0)
Quote Reply
Posted: 22 Feb 2017 at 3:09pm |
|
I don't have a boot drive installed yet. Do you think that would matter? I was planning on running FreeNAS off of a USB.
Here's the setup...  It sounds like it's running. Just no visuals.
|
|
|
|
|
ARAMP1
Newbie
Joined: 22 Feb 2017 Location: Memphis, TN Status: Offline Points: 59 |
Post Options
Thanks(0)
Quote Reply
Posted: 22 Feb 2017 at 3:03pm |
LOL. Man, you're good. I actually did forget it initially and even thought that might be the issue, but unfortunately, plugging it in did nothing. Well, I tried clearing the CMOS and no luck. Any other ideas?
|
|
|
|
|
wardog
Moderator Group
Joined: 15 Jul 2015 Status: Offline Points: 6447 |
Post Options
Thanks(0)
Quote Reply
Posted: 22 Feb 2017 at 1:24pm |
|
hehe, I better ask as it's all too often overlooked.
You didn't forget to plug in the 4-pin ATX12V1 CPU power connection located in the middle of the lower right quadrant did you  |
|
|
|
|
wardog
Moderator Group
Joined: 15 Jul 2015 Status: Offline Points: 6447 |
Post Options
Thanks(0)
Quote Reply
Posted: 22 Feb 2017 at 1:18pm |
|
Well, Kingston shows this stick as compatible.
https://www.kingston.com/us/memory/search?partId=KVR21E15D8%2F16 and https://www.kingston.com/us/memory/search?devicetype=7&mfr=ASR&line=Motherboard&model=93677 If you're able to get into the BIOS check that they're set to its timing specs and at 1.2v. If not, with it unplugged, please remove the CMOS battery from its holder and carefully, using a conductive item, jump the CLRMOS1 pads. Then replace the battery, apply power, and reply back the results of your doing this. |
|
|
|
|
ARAMP1
Newbie
Joined: 22 Feb 2017 Location: Memphis, TN Status: Offline Points: 59 |
Post Options
Thanks(0)
Quote Reply
Posted: 22 Feb 2017 at 11:53am |
|
New guy here...
I did a search and couldn't find anything. I'm building a server with a C236 WSI motherboard. I'm using an Intel E3-1240V5 CPU and one stick of Kingston KVR21E15D8/16 16Gb memory (though I eventually plan on doing two sticks for 32Gb total). I assembled the board today and powered it on. Everything seemed normal however there was no video. (the monitor and cable are confirmed to work). I think it may be a memory issue, but I've read on the interwebs of people using this memory with success (though I don't know if they were using two sticks). Any ideas?
|
|
|
|
|
